This concrete masonry unit lintel detail shows the reinforcing configuration over a wall opening. The assembly consists of concrete masonry units with knocked-out webs to accommodate grout and rebar. Top reinforcing requires a minimum of one number 4 bar, while bottom reinforcing is sized per schedule. Single-leg shear reinforcement with 135-degree hooks wraps around the longitudinal reinforcing. An additional number 5 horizontal bar is required where the lintel depth exceeds 32 inches, and lintel blocks are specified for the bottom course only.
TOP REINF (1-#4 MIN) SINGLE LEG SHEAR REINF PER SCHEDULE w/ 135° HOOK AROUND LONGITUDINAL REINF PROVIDE 1-#5 HORIZONTAL BAR WHERE LINTEL DEPTH IS GREATER THAN 32" CMU COURSE WITH UNIT WEBS "KNOCKED OUT" FOR ALL UNITS LINTEL BOTTOM REINF PER SCHEDULE PROVIDE LINTEL BLOCK FOR BOTTOM COURSE ONLY SECTION A-A (NOMINAL) WIDTH 1/2" MIN (NOMINAL) LINTEL DEPTH WALL OPENING
