A railing by others connects to a structural assembly featuring an HSS member and a shade pocket unit. Fillet welds of one-quarter inch size are specified on three sides typically for the plate-to-HSS connections. Additional note references Case 1 for omitted information.
CASE 2 NOTE: SEE CASE 1 FOR INFORMATION NOT SHOWN 1/4 1/4 3 SIDES, TYP 3 SIDES, PL TO HSS SHADE POCKET, S.A.D. RAILING BY OTHERS
