An HSS beam frames into an HSS column, secured with continuous five-sixteenths inch fillet welds on typical sides. A one-quarter inch cap plate is provided at the top of the column where it occurs. The members are referenced to structural elevations.
1/4" CAP PL TOP OF COLUMN WHERE OCCURS HSS COLUMN REF. ELEVATION HSS BEAM REF. ELEVATION 5/16 5/16 5/16 5/16 TYP.
