This structural plan detail shows a concrete pilaster integrated with a basement wall. The centerlines of the pilaster and the column above coincide at the grid intersection unless noted otherwise on the plan. Wall horizontal reinforcement continues through the pilaster, and basement wall reinforcement runs continuously behind the pilaster. The pilaster concrete strength and vertical reinforcement are sized per the concrete column schedule, while the wall thickness and concrete strength are determined per the plan and general notes. A one-and-a-half-inch clearance is maintained.
NOTES: 1. CENTERLINES OF PILASTER AND COLUMN ABOVE COINCIDE AT GRID INTERSECTION UNLESS NOTED OTHERWISE ON PLAN. 1 1/2" CLR 18" 19" 14" 18" PILASTER CONC PER CONC WALL THICK PER CONC COL SCHED WALL CONC WALL CONC CL COL CL COL REINF PER CONC COL SCHED REINF PER CONC COL SCHED WALL HORIZ REINF CONT THRU PILASTER BSMT WALL REINF CONT BEHIND PILASTER BSMT WALL REINF CONT BEHIND PILASTER f'c PER COL SCHED f'c PER GENERAL NOTES f'c PER GENERAL NOTES PER PLAN COL SCHED 9 TYPICAL PILASTER
