A hanging steel hollow structural section beam connects to a supporting steel beam using a five-sixteenth-inch steel plate and steel angle braces. A steel plate running parallel to the beams knives through the column with bolted connections. A one-quarter-inch fillet weld is applied to three sides typically at the connection points.
A A S301 A1 5/16" STEEL PL HANGING STL HSS BM, SEE PLAN PL PARALLEL TO BMS KNIFES THROUGH COL STL BM WP SECTION A-A AT SIM COND MIDDLE BEAM DOES NOT OCCUR 1/4 3 SIDES TYP STL ANGLE BRACE
