Canopy framing members intersect at a corner utilizing an L4x4x5/16-inch structural steel angle measuring zero feet nine inches long. Three seven-eighths-inch diameter bolts spaced at three inches on center secure the angle to the canopy frame. The connection includes a three-sixteenths-inch fillet weld applied to three sides. Nuts for the bolted connection must be positioned inside the canopy frame.
CL BM BEAMS PER PLAN 1/2" MAX 1 3/4" 1 3/4" 45° 3/16 3 SIDES L4x4x5/16x0'-9" NUT FOR BOLTED CONNECTION TO BE INSIDE THE CANOPY FRAME (3) 7/8"Ø BOLTS @ 3" SPACING
