This structural section details a pedestrian bridge assembly spanning between Level 2 at elevation 96 feet 9 inches and Level 3 at elevation 110 feet 9 inches. HSS10x10x5/8 hanging columns complying with ASTM A1085 and architecturally exposed structural steel category 3 standards are suspended from the upper framing level. The framing incorporates steel beams supporting a metal deck floor system. Dimensions indicate a 10-foot-0-inch spacing between hanging supports and a 2-foot-6-inch clearance from grid line C. A soffit is indicated per architectural drawings below the upper structure.
LEVEL 2 96' - 9" LEVEL 3 110' - 9" C 2 S-628 3 S-628 2'-6" 10'-0" HSS10X10X5/8 HANGING COLUMN, (AESS3), ASTM A1085, TYP 7'-6" SOFFIT SEE ARCH 2'-7 3/4" 6'-11"
