A non-structural wall panel connects to a structural beam per plan using two 43-mil minimum depth channels with 1.5-inch minimum flanges to match the brace. The channels fasten to the framing using number 8 sheet metal screws at 12 inches on center. Powder-actuated fasteners secure the assembly at 24 inches on center. The stud wall typical assembly includes a track with anchors per schedule.
GL BM PER PLAN NON-STRUCTURAL WALL PANEL BY OTHERS (2) 43MIL MIN CHANNEL DEPTH TO MATCH BRACE 1Ï" MIN FLANGES #8 SMS @ 12"oc TO CHANNELS PAF @ 24"oc FOR INFORMATION NOT NOTED SEE 1 S5.4 TRACK W/ ANCHOR PER SCHED STUD WALL, TYP
