An HSS8x8 girt connects to a structural steel column utilizing a WT6x20 shape at an HSS column or a W14 column outrigger, featuring an L5x3x1/2 by zero-foot-five-and-a-half-inch long-legs-horizontal angle secured with two 7/8-inch-diameter A325-N bolts. The girt is detailed with a 3/8-inch end plate and a one-inch-diameter weep hole centered typically, welded with a quarter-inch fillet weld both sides typically and a five-sixteenth-inch fillet weld at the end plate. A WT6x20 measuring one foot two inches long is provided at the HSS8x8 column, and a WT6x20 measuring zero feet ten inches long is provided at the W14 column outrigger.
5/16 1/4 BOTH SIDES TYP 1/4 END PL 1"Ø WEEP HOLE CENTERED TYP L5x3x1/2x0'-5 1/2" (LLH) W/ (2) 7/8"Ø A325-N BOLTS HSS OF WF COL SEE STL COL SCHED WT6x20x1'-2" @HSS8x8 COL WT6x20x0'-10" @W14 COL OUTRIGGER PLAN ELEVATION HSS8x8 GIRT SEE CLADDING ELEVATION W/ 3/8" END PL 5" 3" CL GIRT & ANGLE CL POST & OUTRIGGER TYP 1 1/2" TYP 1 1/2" 3 1/2" SEE CLADDING ELEVATION T/STEEL
