A supported steel beam connects to a supporting beam web via a shear plate and bolts sized per schedule. A full-height stiffener plate is welded to the supporting beam web to match the shear plate when the beam frames on one side only. Dimensions specify a three-inch minimum spacing and one-and-a-half-inch minimum edge distances.
1 1/2" MIN. 1 1/2" 3" MIN. 2" 3" @ 3" 20 S6.1 20 S6.1 A FULL HT. STIFF. PL WHEN BEAM FRAMES ON ONE SIDE ONLY TO MATCH SHEAR PL BOLTS PER SCH. SHEAR PL AND PER SCH.
