A metal deck bears a minimum of two inches onto a structural steel beam supporting a veneer wall with a five-eighths-inch clear space. Dry-pack grout fills the low flutes below the veneer. An angle section L3x3x3/8 connects the assembly, welded with one-quarter-inch fillet welds at two feet six inches spacing.
AT CANOPY B.O.D. 5<" VENEER DRY-PACK GROUT LOW FLUTES BELOW VENEER MTL DECK - 2" BRG MIN. -FOR WELDING SEE L3x3x3/8 STL BM C.F.S. WALL 1/4 2-6 1/4 2-6 1 S5.31 ! STUD & STL BM
