Structural · S-3HDGP

Concrete Slab and Metal Deck Edge Details at Steel Beam

Materials

Elements

About this detail

A reinforced concrete slab poured over metal deck bears on a structural steel beam, anchored with three-quarter-inch diameter by four-inch shear studs spaced at twenty-inch intervals typical at the beam web and angles. Continuous number four reinforcing bars run horizontally with three-quarter-inch clearance to welded wire reinforcement or rebar. An angle profile measuring three by three by one-quarter inches provides additional support. Edge conditions incorporate continuous top and bottom reinforcing bars with specific maximum spacing dimensions.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
