A concrete slab on steel deck transitions to a concrete-encased upturned steel beam, with sizing and placement per plan. A three-inch minimum clearance is maintained to coordinate with future fifty main design elements. Additional framing conditions refer to sheet S6.101.
CONC SLAB ON STL DECK CONC ENCASED, UPTURNED STL BM, SEE 4/S6.101 PER PLAN 50 MAIN DESIGN 3" MIN, COORD W/ FUTURE
