A continuous masonry wall runs parallel to a wide flange beam supporting a concrete slab on steel deck. A bent plate measuring 4x5/16 by 1 foot 3 inches wide connects to the wall with a vertical laminated strand lumber member and two 1/2 inch diameter anchor rods spaced at 12 inches on center grouted in the cell. Two 5/8 inch diameter threaded studs at 9 inch gauge are welded to the bottom of the beam flange to anchor a horizontal laminated strand lumber member parallel to the wall in an angle. A finger tight nut with peened threads prevents loosening at the connection to the underside of the beam. A brace connects to each bent plate, with a maximum 1 foot variation.
CL BM 2 1/2" BOND BM SEE "TYP CMU BRACE TO UNDERSIDE OF CONC ON STL DECK" PROVIDE BRACE AT EA BENT PLATE BENT PL4x5/16x1'-3" WIDE AT "S2" W/ VERT LSL AND (2) 1/2" DIA AR @ 12" OC GROUTED IN CELL CONTINUOUS WALL PARALLEL TO WF BEAM VARIES, 1'-0" MAX WALL EXTENDS TO TYPICAL WALL TOP CONN AT NEXT FLOOR 1 1/2" MIN 1 1/2" MIN (2) 5/8" DIA THREADED STUDS @ 9" GA WELDED TO BOT OF FLANGE. PROVIDE HORIZ LSL PARALLEL TO WALL IN ANGLE AT CONN TO UNDERSIDE OF BM. FINGER TIGHT NUT AND PEEN THREADS TO PREVENT LOOSENING
