Four new long-span open web steel joists, designated as joist one through four of type 32LH SP (200/140), are stabilized with temporary angle bracing consisting of L2x2x1/4 members. The temporary bracing runs across the top chords of the new joists alongside an existing truss.
32LH SP (200/140) (JOIST #4) 32LH SP (200/140) (JOIST #3) 32LH SP (200/140) (JOIST #2) 32LH SP (200/140) (JOIST #1) NEW NEW NEW NEW EXISTING TRUSS TEMPORARY L2X2X1/4 BRACING E2 S406 E2 S406
