An electrical conduit is suspended from the structure above by a half-inch diameter threaded hanger rod and secured with a standard pipe clamp. Unistrut P1000 channel braces are attached to the clamp assembly using Unistrut P1843W hinges on both sides, oriented at a maximum angle of forty-five degrees for seismic restraint. The vertical hanger rod requires stiffening per detail 3/S790, and the upper rod connection to the structure is detailed separately.
FRONT VIEW SIDE VIEW RE: 6/S790 FOR ROD CONNECTION TO STRUCTURE ABOVE 1/2"Ø THREADED ROD ~ STIFFEN HANGER ROD PER DETAIL 3/S790 UNISTRUT P1000 CHANNEL BRACE ELECTRICAL CONDUIT UNISTRUT P1000 CHANNEL BRACE UNISTRUT P1843W HINGE ~ TYP. PIPE CLAMP 45.00° MAX. 45.00° MAX.
