A wide flange W14 steel section with cover plates is anchored to a structural support system incorporating braced frames and slotted connections. Five-eighths inch welds secure the assembly at typical locations with centerlines aligned for frame stability. Additional connection details are referenced back to the primary W14 section drawing.
A 2 CL CL CL CL BRACED FRAME SLOT, TYP SEE SECTION AT W14 FOR CONN INFO ES, TYP 5/8 SECTION AT W14 W/ COVER PLATES
