An intermediate landing connects to a hollow structural section support member using a continuous angle deck support. A C310x31 channel edge member spans between the stair stringers and is welded directly to the HSS intermediate landing member. The C310x31 stair stringer frames into the assembly, aligning with the concrete-filled or metal deck landing construction.
C310x31 EDGE MEMBER BETWEEN STRINGERS, WELDED TO HSS INTERMEDIATE LANDING HSS 152x152x8.0 C/W L51x51x6.4 CONT. DECK SUPPORT C310x31 STRINGER 305 25 TYP.
