An open-web steel joist bears directly on a three-quarter-inch steel cap plate welded to the top of a steel column sized per plan. Bolting is required for all joists with spans greater than or equal to forty feet. Additional connection criteria specify one-eighth-inch by two-inch plates at K-series joists and one-quarter-inch by two-inch plates at long-span LH-series joists. Reference is made to detail D1/S504 for further information.
STEEL COLUMN - SEE PLAN 3/4" CAP PLATE BOLTS REQ'D. FOR ALL JOISTS W/ SPANS ≥40'-0", TYP. 1/8" x 2" AT 'K' 1/4" x 2" AT 'LH' SEE DETAIL D1/S504 FOR MORE INFO. E 6
