Hollow structural section door frame posts span between structural members labeled PC3X-B, PC3Y-B, and PC3Z-B with intermediate spacing dimensions of 8'-3" and 2'-3". Gusset plates connect the framing elements GB3 and GB4 at joint locations. Dimension strings verify centerlines and spacing across the assembly.
PC3Y-B PC3Z-B GB4 GB3 1 S6.01 2' - 3" 8' - 3" 8' - 3" HSS DOOR FRAME POSTS PC3X-B PC3Y-B (11' - 9 5/8") GB4 GB3 1 S6.01 2' - 3" 8' - 3" 8' - 3" HSS DOOR FRAME POSTS
