An anchor bolt schedule defines the required minimum embedment depths for various bolt diameters ranging from one-half inch to one inch in concrete. Minimum bolt spacing is specified as twelve bolt diameters with a minimum edge distance of six diameters. A hooked anchor bolt detail shows the face of concrete, minimum embedment depth per schedule, and a two-inch minimum unless noted otherwise.
ANCHOR BOLT SCHEDULE 1/2" 3/4" 5/8" 7/8" ANCHOR BOLT DIAMETER 1" 7" 5" 6" 5" 5" EMBEDMENT FACE OF CONC NOTE: MINIMUM BOLT SPACING SHALL BE 12 BOLT DIAMETERS WITH A MINIMUM EDGE DISTANCE OF 6 DIAMETERS. SEE SCHEDULE MIN EMBEDMENT UNO 2" MIN NTS 15 TRIM BARS AT RE-ENTRANT CORNERS
