A structural connection at an existing wall core with an existing channel embedded into the masonry wall. The existing brick in mortar must be verified in sound condition after coring, with loose material removed and filled with grout. The existing channel may be positioned flush to the face of the wall. Framing connections at Level 2 are referenced to related details for complete installation requirements.
CL SYM. NOTE: SEE DETAIL 3 FOR INFO NOT NOTED (E) CHANNEL. VERIFY EMBEDMENT INTO WALL. (E) CHANNEL MAY BE FLUSH TO F.O. WALL. SEE PLAN CORE VERIFY (E) BRICK IN MORTAR ALL SIDES CORE IN SOUND CONDITION AFTER COMPLETING CORING. REMOVE LOOSE AND DAMAGED MATERIAL AND FILL WITH GROUT. (E) LEVEL 2 SEE REFERENCED DETAILS FOR FRAMING SEE REFERENCED DETAILS FOR FRAMING
