A stepped bottom condition in a concrete wall panel features vertical reinforcement. Typical vertical reinforcement is provided, with remaining vertical reinforcement omitted for clarity. Additional corner reinforcement consists of two number five bars measuring four feet long typically. Dimensions indicate a maximum three-inch step constraint. Bottom bars are referenced to detail 1 on sheet SD.3, and the stepped footing is referenced to detail 10.
