A structural foundation pile cap plan shows the geometric arrangement of six piles designated P255, P256, P257, P258, P555, and P584 arranged in a symmetrical grid. Center-to-center dimensions space the piles by 1'-9" horizontally from the centerline and 3'-6" vertically between rows. Additional structural grid intersection bubbles P379 and P392 reference the coordinate locations on the broader foundation plan. A boundary outline defined by a cloud line indicates the extent of the pile cap concrete element.
