Two concrete tilt-up panels meet at a three-quarter-inch panel joint with embedded deck bearing plates. Post-installed anchors secure the connection within the concrete panels. Special instructions require drilling a new hole in the angle at least six inches away if the distance from the tilt edge to the anchor is less than four inches.
3/4" PANEL JOINT CONC TILT-UP PANEL DECK BRG EMBED PL PER NOTE 1, IF "X" (DISTANCE OF TILT EDGE TO POST INSTALLED ANCHOR) IS LESS THAN 4", DRILL A NEW HOLE IN ANGLE AT LEAST 6" AWAY "X"
