A buckling-restrained brace connection frames into a steel beam with five-eighths-inch thick gusset plates. Five-sixteenths-inch stiffener plates are welded on each side and each face of the beam web. The buckling-restrained braces and bolts are installed per manufacturer specifications, with specific edge distances and work point elevations provided. Fillet welds of five-sixteenths-inch size are indicated at the gusset connections.
2" 2" 4' - 0" ** WP BRB AND BOLTS PER MFR SEE S-611 FOR ADDL INFO GUSSET PL5/8 5/16 48 5/16 48 TYP TOS EL 116' - 2 1/2" 5 1/2" STIF PL5/16 EA SIDE, EA FACE 12" MAX GUSSET PL5/8 6" MAX 7 9 6 8 10
