A top K-brace connects to a hollow structural section column and braced frame beam supporting metal roof deck and roof joists. The hollow structural section brace frames into a gusset plate welded to the underside of the beam, maintaining a one-inch minimum clearance. A beam splice is located near the brace point with complete joint penetration welds or optional flange plates with slip-critical bolts. A dragline and shear connection plate ties the beam through the column, accommodating lateral loads in the direction of the dragline force.
WP COL HSS COL PER PLAN P E DRAGLINE/SHEAR CONN THROUGH PL THROUGH PL GUSSET IF REQD, TYP W-BM PER PLAN, TYP BRACE BRACED FRAME BM MTL ROOF DECK PER PLAN TYP 1" MIN GUSSET PL ROOF JOIST PER PLAN BEYOND, TYP MIN 1' - 0" 1/2" BM SPLICE HSS BRACE PER ELEV C L C L C L NS/FS IF REQD NS/FS MIN 2" NS/FS NOTES: 1. P E INDICATES DIRECTION OF DRAGLINE FORCE. 2. FLANGE PLATES WITH SLIP CRITICAL BOLTS MY BE USED IN LIEU OF CJP FLANGE WELDS AT BEAM SPLICE LOCATIONS. CJP TYP
