A concrete over metal floor deck terminates at an opening framed by W8x10 steel beams and cross beams. A closure plate is detailed at the edge of the slab and metal deck. Steel framing connections utilize bolted shear tabs or angles as referenced by detail callouts.
W8x10 MIN CLOSURE PL DET (XXX) CONC OVER MTL FLR DECK STL BM W8x10 CROSS BMS 1" 2 S802 7 S601 2 S802 7 S601 SEE ARCH / MECH
