The table lists vibration patterns labeled A and B along with their corresponding magnitudes in micro-inches per second (u-in / sec) and MIPS. General structural notes specify office vibration design limits and reference AISC Design Guide-11 for moderate pace walking criteria.
Text on the drawing
VC-B 4,000 MIPS VIBRATION TABLE MAGNITUDE (u-in / sec) PATTERN 8000 MIPS B A NOTES: 1. ELEVATED FLOOR IS DESIGNED FOR OFFICE VIBRATION WITH MAX OF 16,000 MIPS. 2. VIBRATION AS PER MODERATE PACE WALKING (75 STEPS/MIN, AISC DESIGN GUIDE-11)
