An embedded wide-flange steel beam acts as a vertical support member within a reinforced concrete wall corner. Shear studs are welded to the web and top and bottom flanges of the beam for composite action with the surrounding concrete. Two rows of fourteen 1 1/8-inch diameter A490 bolts connect to the embedded W21 section. Continuous top and bottom reinforcing bars and vertical stirrups reinforce the concrete corner around the steel beam. A deck support angle is anchored at the underside of the concrete slab to receive the metal deck spanning from the wall.
(2) ROWS OF (14) 1 1/8" DIA A490 BOLTS, TYP AT W21 B EMBEDDED W21 Lsb DECK SUPT PER TYP DETS (2) 3/4" DIA x 4 1/2" STUDS @ 12" OC, TYP ES WEB (3) 3/4" DIA x 8" STUDS @ 6" OC, TYP T&B FLG WALL REINF PER ELS WALL REINF PER ELS EL = 101'-8" #6x @ 6" (2) #11 CONT T&B #6x @ 6" T&B 7'-6"
