A wide flange beam sized per plan connects to a hollow structural section hanger sized per plan with a one-half-inch gusset plate. Five-sixteenth-inch welds with ten-inch and twelve-inch spacings secure the connection components to the hollow structural section header below the center post.
GRID 5/16 10" 5/16 10" 5/16 12" 5/16 12" ON HSS HDR BLW CENTER POST HSS HGR, SEE PLAN GUSSET PL 1/2" WF BEAM, SEE PLAN
