Concrete slab step transition showing top and bottom reinforcement continuous through the offset with required laps. The step height is defined as dimension X with a maximum limit of one foot and six inches, while the horizontal transition dimension is set to six times dimension X unless otherwise noted on plan. Number four top and bottom bars are placed at eighteen inches on center with continuous laps as required. Bottom and top bars continue as specified per plan across the elevation change.
1' - 6" 36" 1' - 6" 12" 12" BOT BARS PER PLAN #4 T&B CONT LAP 2'-0" AS REQD #4x @ 18" T&B TOP BARS PER PLAN SLAB STEP DIM PER PLAN 1' - 0" MAX "X" DIM = 6X UNO ON PLAN MIN X MIN
