A masonry wall control joint is configured in both elevation and horizontal section views. The joint width ranges from three-eighths to one-half inch and is finished with a backup rod and caulking. Vertical reinforcement and alternate ladder horizontal reinforcement are detailed for each section condition. Mortar joints are raked one-half inch deep at the control joint interface. Horizontal reinforcement either continues through the joint only at ledgers and lintels or stops short depending on the specific section detail.
SECTION A-A SECTION B-B A A B B EL. OF MASONRY WALL W/ CONTROL JOINT HORIZ. REINF. VERT. REINF. MORTAR JOINT RAKED 1/2" DEEP HORIZ. REINF. VERT. REINF. BACKUP ROD CAULKING HORIZ. REINF. CONTINUOUS THROUGH JOINT ONLY AT LEDGER OR LINTEL HORIZ. REINF. DOES NOT CROSS JOINT HORIZ. REINF. VERT. REINF. CONTROL JOINT 3/8" TO 1/2" 1/2" ALTERNATE LADDER HORIZ. REINF. PER GENERAL NOTES ALTERNATE LADDER HORIZ. REINF. PER GENERAL NOTES
