A structural brace connects to a wide-flange beam supporting a metal roof deck that spans in the opposite direction. Brace locations are coordinated per framing plans, with unshown conditions referenced to the composite deck detail.
METAL ROOF DECK SPANS OPPOSITE DIRECTION AT SIM. NOTES: 1. REF. DESIGNATION ON FRAMING PLANS FOR BRACE LOCATIONS. 2. FOR INFORMATION NOT SHOWN REF. DETAIL AT COMPOSITE DECK. REF. PLAN AT PARALLEL ROOF DECK
