An embed plate assembly features an embed plate with three-quarter-inch diameter by six-inch headed studs per the schedule. The plate layout includes one and one-half inch edge distances, three-inch transverse spacing, and a nine-inch maximum with four and one-half inch minimum row spacing. Top of wide flange and bottom of wide flange elevation markers reference the vertical positioning.
1 ½" 3" 3" 9" MAX., 4 ½" MIN. ROW SPACING, TYP ® ¯ EMBED PLATE W/ ¾"Øx6" HEADED STUDS PER SCHEDULE 1 ½" 1 ½" 1 ½" 2 ½" MIN. T.O. WF B.O. WF
