S-2C7HM — Horizontal Construction Joint in Shotcrete

Structural · S-2C7HM

Horizontal Construction Joint in Shotcrete

Units: metric
Sheet: S5.02
Discipline: Structural

Materials

Concrete Reinforced Concrete

Elements

Bearing Walls Expansion / Control Joints Reinforcing Walls Waterproofing / Flashing

Connections

Expansion / Slip Connection

Text on the drawing

ROUGHEN SURFACE AND REMOVE LOOSE MATERIAL CLEAN WALL AND REBAR OF REBOUND FIRST SHOTCRETE PLACEMENT SECOND SHOTCRETE PLACEMENT NOTES: 1. CONTRACTOR TO SUBMIT PROPOSED JOINT LOCATION TO ENGINEER FOR REVIEW. JOINT LEVEL FORMWORK BY OTHERS WATERSTOP, REF. 16/S5.02
