Cold-formed metal stud framing bears against a structural steel beam supporting a metal roof deck. Six-inch eighteen-gauge metal studs spaced at eight inches on center connect to a continuous bottom track and a box beam head track. Stiffclip LS clips attach each stud to the box beam using two number twelve self-tapping screws into both the box beam and the stud. A two-inch twenty-gauge strap fastens with number twelve self-tapping screws into each flange at sixteen inches on center. A brace connects to the steel beam per architectural specifications at four-foot maximum spacing.
METAL ROOF DECK STEEL BEAM, SEE PLAN GLAZING, SEE ARCH BRACE PER 8/S511 AT 4'-0" O.C. MAX 6"x18GA (600S162-43) METAL STUDS AT 8" O.C. STIFFCLIP 'LS' AT EACH STUD WITH (2) #12 STS INTO BOX BEAM AND STUD (2) 6"x18GA (600S162-43). STRAP WITH 2"x20GA STRAP AT 16" O.C. FASTEN WITH #12 STS INTO EACH FLANGE 6"x16GA (660T125-43) x CONT BOTTOM TRACK 12A S511 12C S511 7 S521
