A galvanized hollow structural section column receives a three-sixteenths inch galvanized cap plate welded at the top. Galvanized hollow structural section beams frame into the upper portion of the column, secured with typical quarter-inch fillet welds. A half-inch diameter weep hole is provided typically near the connection. All vent holes are plugged after galvanization to create an airtight column assembly below the roof deck.
GRID BOD EL PER PLAN 113' - 4 1/2" RF DK PER PLAN 1/4 1/4 TYP 5/16 TYP 1/2" DIA WEEP HOLE, TYP GALV HSS BM PER PLAN GALV COL PER PLAN, PLUG ALL VENT HOLES AFTER GALV TO CREATE AN AIRTIGHT COLUMN GALV CAP PL3/16
