A glulam timber column bears on a wide-flange steel beam with top and bottom plates sized to match the glulam column dimensions. Four one-inch diameter epoxy rods extend through the connection with a minimum embedment of three inches and a length of one foot six inches. One-half-inch stiffener plates are provided on each side, welded with fillet welds of varying sizes including quarter-inch and five-sixteenth-inch welds. A wide-flange WT shape frames into the web of the supporting beam with a three-sixteenth-inch typical weld and three-eighths-inch plates. Steel beams framing into timber columns utilize typical connection type C30.
SECT SECT WT ON WF 1 1/2" 1/2" TYP 1/2" TYP CL COL PER PLAN TIMBER FL NOT SHOWN GL COL TOP WF PL1 TYP, MATCH GL COL DIMS GL COL BOT MIN EMBED 3" W/ 1'-6" (4) 1" DIA EPOXY RODS T&B STIFF PL1/2 ES, TYP TOS SECTION GAGE AISC WORKABLE TYP 3/16 TYP 5/16 5/16 1/4 1/4 PL3/8, TYP W8, NOTE 1 NOTES: 1. SEE "TYPICAL SHALLOW BEAM CONNECTION". STL BM SECTION NOTES: 1. USE "TYPICAL STEEL CONNECTION TYPE C30" FOR STEEL BEAMS FRAMING INTO TIMBER COLUMNS. 4 19 TYPICAL TIMBER COLUMN CANTILEVERED CONNECTION 14 TYPICAL TIMBER COLUMN ON STEEL BEAM
