Wood floor framing bears on the top flange of a structural steel beam with a required minimum bearing of 2 inches typical. Seven-inch-long 3/4-inch diameter Nelson studs spaced at 12 inches on center anchor the assembly. An L3x3x3/8 angle supports the framing connection, secured with quarter-inch fillet welds spaced 3 inches on 12-inch centers.
42 BEARING TYP 2" MIN 3-12 3-12 1/4 1/4 1 3/4" 7" LONG 3/4" DIA NELSON STUD @12 OC L3x3x3/8 DETAIL A
