Hollow structural section truss braces connect to a structural steel truss bottom chord and a wide-flange beam using slotted knife plates welded with five-sixteenth-inch fillet welds. The brace members consist of HSS6x6x5/16 sections slotted to receive a one-half-inch knife plate, secured with three-quarter-inch machine bolts or A325N bolts. A one-half-inch flush knife plate aligns with the truss bottom chord flange, while three-eighth-inch stiffener plates are welded to each side of the wide-flange beam web aligned with the working point.
2" EQEQ 6" TRUSS WEB HSS6x6x5/16 BRACE SLOTTED PER 2 1 TRUSS BOT. CHORD 5/16 5/16 (1) 3/4"' M.B. KNIFE 1/2" FLUSH W/ TRUSS BOT. CHORD FLANGE CLIP AS REQ'D 5/16 5/16 15 S52-01 1½" 1½" 1½" 3" 1½" EQEQ 2 1 STIFF. 3/8" EA. SIDE ALIGN WITH W.P. WF BM PER PLAN KNIFE 1/2" (2) 3/4"' A325N BOLTS HSS TRUSS BRACE PER 6 S53-01 5/16 6 5/16 6
