A concrete slab on grade thickens by two inches at the tilt-up wall panel, increasing to four inches at overhead door openings, and rests on a concrete footing with a 1 1/2-inch non-shrink grout bed, foundation insulation, and an L8x8x1/2 steel angle anchored by 3/4-inch diameter by 5-inch heavy-duty sleeve anchors at 18 inches on center. Additional connection is provided by number 4 dowels at 18 inches on center, which may be drilled and epoxied at the contractor's option, along with a number 4 horizontal bar spanning the opening width and an L-shaped steel angle at non-ramp locations.
1 1/2" NON-SHRINK GROUT #4x18"x36" (LLH) DOWEL @ 18" O.C. (DRILL AND OPOXY AT CONTRACTORS OPTION) CONC SLAB ON GRADE CONC TILT-UP PANEL BEYOND #4 BAR HORIZ. x OPENING WIDTH THICKEN SLAB 2" AT PANEL (4" @ OVERHEAD DOOR OPENINGS) 11 S104 CONC FOOTING 30" MIN. 4'-0" CONC SLAB ON GRADE - SLOPE AWAY FORM BUILDING FOUNDATION INSULATION 4"x4" STEEL ANGLE NO RAMP LOCATIONS L8x8x1/2 w/ 3/4" Ø x 5" HSA @ 18" O.C.
