A concrete slab on metal deck construction joint assembly features #4 continuous reinforcing bars and #4 dowels spaced at 12 inches on center crossing the cold joint interface. Two inches of concrete clearance are maintained at the formed joint edges, with slab-on-deck reinforcement detailed across the corrugated metal decking profile.
SCALE: 7 - TYPICAL SLAB ON DECK CONSTRUCTION JOINT NONE SECTION A-A S.A.D. SAD 12" 2" CLR EQ EQ 2" CLR S.A.D. S.A.D. 2" CLR #4 @12"o.c., EW COLD JOINT #4 DOWELS @12"o.c. 12 A A #4 @12"o.c. #4 CONT
