A reinforced concrete footing supports a concrete pier that extends upward as a foundation wall. Horizontal wall reinforcing runs continuously through the pier. Vertical column dowels match the reinforcement above and anchor into the footing. A concrete slab on grade ties into the side of the pier as specified on the structural plans.
DOWEL TO MATCH VERT COLUMN REINF ABOVE CONCRETE PIER, SEE PLAN AND SCHED AT CONCRETE PIER RUN HORIZONTAL WALL REINFORCING CONT THROUGH PIER CONCRETE SLAB ON GRADE, SEE PLAN CONCRETE FOOTING, SEE PLAN AND SCHED
