A 1-1/2 inch floor track, sized in width and gauge to match the studs unless otherwise noted, sits atop the concrete slab or curb. The track is secured with 0.145-inch diameter by 1-inch low velocity fasteners spaced at 12 inches on center. Number 10 screws fasten each side at each stud where required. A slab or deck edge condition occurs at the boundary, and a joint plan view details the six-inch spacing configurations.
6" 6" JOINT PLAN VIEW 0.145"Øx1" LVF @ 12" TOP OF SLAB 1 1/2" FL TRACK - WIDTH AND GUAGE TO MATCH STUDS UNLESS OTHERWISE NOTED SLAB OR DECK EDGE WHERE OCCURS #10 SCREWS EA SIDE @EA STUD TYP WALL ON SLAB OR CURB 6" OR WIDER 3 1/4" TRACK
