A skewed structural steel beam connects to a column flange using complete joint penetration welds with a specified maximum clearance of one-half inch. A stiffener plate aligns with the skewed connection plate and matches its thickness. Additional beam connections occur as indicated on plan. For further information not noted, refer to sheet S5.1.
¢ BM ¢ BM/COL ¢ BM/COL STIFF £ ALIGN W/ SKEWED CONN £ THICKNESS TO MATCH SKEWED CONN £, Ï" MAX CJP ES CJP MAX 9 " A TO FLANGE FOR INFORMATION NOT NOTED SEE 10 S5.1 11 S5.1 BM ES AS OCCURS
