A pressure-treated three-times sill plate anchors to a concrete wall or footing via anchor bolts sized per the shearwall schedule. A standard cut washer and a Simpson BPS or approved equal hardware secure the wood member to the foundation, maintaining a maximum half-inch offset as indicated. Shearwall plywood sheathing fastens to the framing with edge nailing sized per the structural schedule.
1/2" MAX. , TYP. STANDARD CUT WASHER SIMPSON BPS OR APPROVED EQUAL P.T. 3x SILL PLATE A.B. PER SHEARWALL SCHED CONC. WALL OR FOOTING E.N., PER SHEARWALL SCHED, TYP. SHEARWALL PLYWOOD SHEATHING PER PLAN STUD WALL PER PLAN
