A floor-mounted appliance stands against a finished wall with a maximum height of 80 inches. The top of the unit is secured to the wall using a 14 gauge clip angle positioned 1 1/4 inches below the top surface. The appliance rests on the finished floor with each front leg anchored per specific detail requirements spaced at a maximum of 5 feet on center. Single units are restricted to a maximum width of 60 inches.
FINISHED FLOOR NOTE: MAXIMUM UNIT WIDTH 60" (1525 mm) SINGLE UNIT USE DETAIL 'A' FIGURE A-22 EACH FRONT LEG (5' MAX. C.C.)(1525 mm) FIGURE A-11 FLOOR MOUNTED APPLIANCE AGAINST WALL 14 GA. (1.98 mm) CLIP ANGLE PER DETAIL ON FIGURE A-25 FACE OF WALL 1 1/4" (32 mm) (2032 mm) 80" MAX. (152 mm) 6" MAX.
