An end stop clip provided by the manufacturer is secured to a four-inch by six-inch by three-sixteenth-inch ASTM A36 steel angle using a one-quarter-inch bolt. The assembly fastens into the metal stud end using two number twelve self-tapping sheet metal screws.
1/4" BOLT 4" X 6" X 3/16" A36 ANGLE (2) #12 SELF-TAPPING SMS INTO METAL STUD END STOP CLIP PROVIDED BY MANUFACTURER
