A service faucet with an integrated vacuum breaker and spout with hose end and pailhook mounts above the basin, stabilized by a spout brace. The basin features a metal edge and stands ten inches high, set above a floor structure with a drain connected to a three-inch diameter P-trap.
36" 10" H C SPOUT BRACE DRAIN METAL EDGE 3" DIA. P-TRAP SERVICE FAUCET WITH VACUUM BREAKER SPOUT WITH HOSE END AND PAILHOOK NONE 2 MOP SINK DETAIL
